Elation Pulse Panel

Condition: B-Stock (Good)
Warranty: 1-Year Manufacturer Warranty
Ships From: United States
Manufacturer: Elation Professional
Model #: PUL001
Item #: 57338 (Brokered)

Overview:
The Elation PULSE PANEL is a multi-functional powerhouse designed for today’s most demanding lighting designers. Whether used as a strobe, blinder, high-output wash light, or dynamic pixel effect, the PULSE PANEL delivers with flexibility, power, and precision—all in an IP65-rated housing built to withstand any environment.

Key Features:
• Massive Output: Over 100,000 total lumens
• RGB Array: 1,152 x 1.5W RGB LEDs in 24 perimeter zones (6×4 grid)
• Strobe Power: 288 x 5W CW LEDs (center strobe line) + 144 x 5W CW LEDs (top & bottom)
• StrobeLine: 96 x 1.5W RGB LEDs in 12 zones
• Adjustable Color Temperature: 2400K–8500K with virtual gel library
• Custom FX: Built-in library of customizable RGB & CW strobe effects
• Connectivity: DMX, RDM, Art-Net, sACN, KlingNet, and Aria x2 wireless device management
• Interlock Mounting: Unique array system for vertical or horizontal configurations
• Durable Design: IP65-rated enclosure with airline tracks and accessory support

Performance Specs:
• Total Lumen Output:
• All LEDs: >75,000 lumens
• CW LEDs: >100,000 lumens
• RGB LEDs: >40,000 lumens
• CRI: >70
• Beam Angle: 68°
• Field Angle: 112°
• Strobe Rate: 1–20Hz
• LED Life: 50,000 hours average

Control & Connectivity:
• 9 DMX modes (3ch to 180ch)
• 4-button menu with LED display
• IP65-rated 5-pin DMX I/O, RJ45 (Art-Net/sACN/KlingNet), and locking power input
• Aria x2 for wireless device management

Physical Specs:
• Dimensions: 11.78” (L) x 16.53” (W) x 8.26” (H)
• Weight: 30.2 lbs (13.7 kg)

$2,100.00
