Specifications:
- DMX Channels: 8 or 14
- DMX Connectors: 3-pin XLR
- Pan and Tilt: 540°/270°
- Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 270° tilt
- Colors: 14 + white, split colors, continuous scroll at variable speeds
- Gobos: 17 + open (all aluminum), fixed, continuous scroll at variable speeds
- Light Source: (included): Osram Sirius HRI 140 W discharge lamp (6,000 hrs)
- (optional): Osram Sirius HRI 132 W discharge lamp (6,000 hrs)
- Strobe Rate: 0 to 20 Hz
- Beam Angle: (beam): 3°
- (frost): 21°
- Illuminance: (5 m): 381,500 lux
- (15 m): 37,900 lux
- Power Linking: 3 units @ 120 V; 6 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current: 228 W, 2 A @ 120 V, 60 Hz
- 224 W, 1.2 A @ 230 V, 50 Hz
- Weight: 25.8 lb (11.7 kg)
- Size: 12.7 x 8.6 x 16.5 in (322 x 220 x 420 mm)Approvals: CE, MET
- Optional Controllers: IRC-6
- Prism: 16-facet round, bidirectional rotation at variable speeds
What’s in the box?
- Power cord
- Hanging bracket
- Warranty card
- Quick Reference Guide
